ReferenceGagesHighPrecisionSquareSERIES311•TheHigh-PrecisionSquaregageisusedforinspectingthetravelstraightnessandaxialperpendicularityofmovingelementsonequipment,suchasmachinetoolsandCMMs.•Fourprecision-lappedreferencesurfaces,nishedusingultra-precisiontechnologybuiltonourexperienceingaugeblocks.•Betterthan1μm/300mmstraightnessandperpendicularityofeach(four)referencesurface.Inaddition,frontandbackfacesareaccuratetobetterthan5μm/300mm.•Threenominalsizesareavailable(90×110,160×210and260×310mm)sothatyoucanselectthesizethatbestsuitstheapplication.311-113Perpendicularitytolerance(μm)Straightnesstolerance(μm)ReferencesurfaceFront/backfacesReferencesurfaceFront/backfaces1515Dimension(W×L×T)(mm)90×110×25160×210×25260×310×30Mass(kg)1.55.014.0SPECIFICATIONSMetricCodeNo.311-111311-112311-113*•Dedicatedwoodencaseisprovided.*Suppliedwitharemovablehandle.ReferenceGages01-47
| <
|
> |
>>
