Mitutoyoreservestherighttochangeanyorallaspectsofanyproductspecification,includingprices,designsandservicecontent,withoutnotice.DigimaticIndicatorsHigh-performanceABSDigimaticIndicatorID-FNX(BidirectionalCommunicationSupported)SERIES543—withBack-litLCDScreen•ID-FSeriesisanext-generationindicatorwithvariousnewfunctions,supportingbidirectionalcommunication.Withtheadditionoftheappropriatedatacableandsoftware,remotezerosettingandgagesettingcanallbeimplementedfromaconnectedPC,therebyimprovingyourworkefciency.•Thisseriesadoptsanexternalpowersupplytooperateabrightbacklitdisplay.Thedisplaycolorhelpsyoumaketolerancejudgmentataglance.GreenindicationforGOjudgmentRedindicationfor±NGjudgment543-851543-853•Thenextcalibrationduedatecanbesetwithanalarmtoimproveinstrumentmanagement.•TheABS(ABSOLUTE)scalerestoresthelastoriginposition*automaticallywhentheindicatoristurnedon,andrealizeshighreliabilitybyeliminatingover-speederrors.*Referto“Precautionsforuse”onpage07-2.Resolution0.0005mm50readings/sResolution0.001mm,0.01mm500readings/s1)Samplingrate:2)Capturingspeed:Functions•Peakdetection(MAX/MIN)•Runoutrangemeasurement(MAX-MIN)Note:PeakdetectionResolution0.0005mm50µm/sResolution0.001mm,0.01mm500µm/s•Zero-setting(INCsystem)•Presetting(ABSsystem)•Measuringdirectionswitching•Tolerancejudgment•Resolutionswitching•Simplecalculationf(x)=Ax•Analogresolutionselection•Datahold(whennotconnectedtoanexternaldevice)•FunctionLock•Calibrationschedulewarning•Dataoutput•Displayrotation(330°)•ErroralarmdisplaySPECIFICATIONSMetricISO/JISType543-855CodeNo.*3Range(mm)Resolution(mm)Maximumpermissibleerror(MPE)*1(mm)PartialmeasuringrangeMPEPTotalmeasuringrangeMPEEHysteresisRepeatabilityMPEHMPERMaximumpermissiblelimit(MPL)Measuringforce(N)PowersourceMass(g)543-855543-855B(atback)543-851543-853543-85712.725.450.80.0005/0.001/0.01(selectable)0.00250.00250.0040.0030.0040.003Inch/MetricASME/ANSI/AGDType0.0020.0021.5orless1.8orless2.3orlessCodeNo.*3RangeResolution543-856543-856B(atback)543-852543-854543-8580.5in/12.7mm1in/25.4mm2in/50.8mm0.00002/0.00005/0.0001/0.0005/0.001in,0.005/0.001/0.01mm(selectable)Maximumpermissibleerror(MPE)*1(in)Overall*2HysteresisRepeatability±0.00010±0.00016±0.000120.000080.00008Maximumpermissiblelimit(MPL)Measuringforce(N)0.9orless1.8orless2.3orlessACadapter(5.9V)180170240330PowersourceMass(g)200170240330ACadapter(5.9V)•Display:7-digitdisplay,sign,andanalogbarwith2-colorbacklight•Responsespeed:Unlimited*1Thesevaluesapplytonormalmeasurementsat20°C.*2Overallmagnicationandlinearity*3TodenoteyourACpowercableaddthefollowingsufxestothecodeNo.:AforUL/CSAandPSE,DforCEE,DCforCCC,EforBS,KforKC,NosufxisrequiredforJIS/100V.ProductcatalogE12049Video07-3
| <
|
> |
>>
